UP LED C

Safety luminaire

Downlight with housing and cover made of sheet steel. High-power LED with light guidance through special lenses for asymmetrical shining light distribution (illumination of escape routes with 1 lx) or symmetrical shining light distribution (illumination of areas with 0.5 lx). Three optics in one luminaire - Through three supplied lenses (1x asymmetrical and 2x symmetrical for 3.5 m and 7 m mounting height).

Version for surface ceiling mounting










TECHNICAL DATA - GENERAL
Housing:
Sheet steel, white (RAL 9010)
Cover:
Sheet steel, white (RAL 9010)
Lens: PMMA, transparent
Service life L80B20: 50.000 h
Color stability: 3 SDCM
Color temperature: 4.000 K
Color rendering index: 70
Optic interface: LIFE
Commissioning: For Autotest, operating duration, operating mode PS, monitoring group and test duration are only programmable per app B.connect over smartphone locally on luminaire.
TECHNICAL DATA - SELF-CONTAINED SUPPLY
Mains supply:
198 V – 254 V / 50 Hz
Switching: Maintained and non-maintained
Ambient temperature:
0 °C to +40 °C
Protection class: I
TECHNICAL DATA - DECENTRAL SUPPLY
Mains supply:
24 V +/- 20 % DC
Battery supply: 24 V +/- 20 % DC
Ambient temperature:
-20 °C to + 40 °C
Protection class: III
TECHNICAL DATA - CENTRAL SUPPLY
Mains supply:
198 V – 254 V / 50 Hz
Battery supply: 176 V – 276 V
Ambient temperature:
-20 °C to + 40 °C
Protection class: I
Mains supply (alt.): 90 V – 254 V / 50/60 Hz
Battery supply (alt.): 90 V – 276 V
