FM repeater
Accessories
Repeater for Logica FM. Amplification of the radio signal on respective position in the radio network. Integrated Logica FM interface according to the ZigBee® standard.
| TECHNICAL DATA - GENERAL | |
|---|---|
| Housing: |
Polycarbonate, grey (RAL 7035)
|
| Dimensions (H x W x D): |
80 x 160 x 60 mm
|
| Type of protection: | IP66 |
| Protection class: | II |
| Mounting: | Surface wall mounting or surface ceiling mounting |
| Mains supply: | 198 V–254 V / 50 Hz |
| Ambient temperature: |
0 °C to +40 °C
|
| Battery: |
LIFE 6.4 V / 1.5 Ah
|
| Compatible test devices: |
Logica FM (21102)
|
